| State | Ibiraci-MG/ Sacramento-MG |
|---|---|
| River name | Paraná |
| sub-basin name | Grande |
| Company name | FURNAS |
| Latitude | 20°17'8"S |
| Longitude | 47°4'0"W |
| Construction Period | 1957-1974 |
| Total installed power(MW) | 476 |
| Destination of Energy | SP |
| Historical Maximum discharge(m3/s) | |
| Mean discharge (m3/s) | |
| Historical minimum discharge (m3/s) | |
| Basin area (km2) | 250 |
| maximum operational water level (m) | 666.12 |
| extreme maximum water level (m) | 666.12 |
| operational water level (m) | |
| minimum operational water level (m) | 653.12 |
| Total volume (m3) | 4,04 bilhões |
| Net volume (m3) | 2,5 bilhões |
| Length (km) | |
| Surface area at normal condition (km2) | |
| Downstream water level(maximum) (m) | |
| Downstream water level(normal) (m) | |
| Downstream water level(minimum) (m) | |
| Height of the spillway outlet (m) | |
| Height of the main dam (m) | 72 |
| Length of the main dam(m) | |
| Vaciemiento máximo / Capacidad de descarge del vertedor (m3/s) | 9350 |
| Tipo | segmento |
| Número de Compuertas Total | 11 |
| superfície | |
| Base | |
| Largo (m) | 10.67 |
| Altura (m) | 12.98 |
| Cota del tipo de ogiva | |
| Longitud de la cresta (m) | |
| Número de unidades instaladas | |
| Potencial nominal (MW) | 2 X 40 MW, 6 X 49 MW, 2 X 52 MW |
| Tipo | Francis |
| Ancho Total (m) | |
| Largo Total (m) | |
| Desnível (m) | |
| Referencia | |
| Otro información | 2 X 40 MW, 6 X 49 MW, 2 X 52 MW T/G supplier: DePretto Escher Wyss, SMS, WHC, CGE, Willamette, Kvaerner, BBC |
