Global Lakes & Reservoirs Repository - GLR
| State | Cachoeira Dourada MG/ Itumbiara-GO |
|---|---|
| River name | Paraná |
| sub-basin name | Paranaíba |
| Company name | Centrais Elétricas Cachorira Dourada |
| Latitude | 18°30'6"S |
| Longitude | 49°29'27"W |
| Construction Period | 1966 (Operation: 1958-1994) |
| Total installed power(MW) | 658 |
| Destination of Energy | MG, SP |
| Historical Maximum discharge(m3/s) | |
| Mean discharge (m3/s) | |
| Historical minimum discharge (m3/s) | |
| Basin area (km2) | |
| maximum operational water level (m) | |
| extreme maximum water level (m) | |
| operational water level (m) | |
| minimum operational water level (m) | |
| Total volume (m3) | |
| Net volume (m3) | |
| Length (km) | |
| Surface area at normal condition (km2) | 74 |
| Downstream water level(maximum) (m) | |
| Downstream water level(normal) (m) | 400.52 |
| Downstream water level(minimum) (m) | |
| Height of the spillway outlet (m) | |
| Height of the main dam (m) | 26 |
| Length of the main dam(m) | |
| Vaciemiento máximo / Capacidad de descarge del vertedor (m3/s) | 16000 |
| Tipo | Superfície |
| Número de Compuertas Total | 10 |
| superfície | |
| Base | |
| Largo (m) | |
| Altura (m) | |
| Cota del tipo de ogiva | |
| Longitud de la cresta (m) | |
| Número de unidades instaladas | |
| Potencial nominal (MW) | |
| Tipo | |
| Ancho Total (m) | |
| Largo Total (m) | |
| Desnível (m) | |
| Referencia | |
| Otro información | Configuration: 2 X 15 MW Kaplan, 2 X 51 MW Francis, 3 X 72 MW Kaplan, 2 X 95 MW Kaplan. T/G supplier: Neyrpic, CKD, CGE, Alsthom-Jeumont, BBC, Ansaldo |
