Governador Ney Aminthas de Barros Braga (Segredo)
| State |
Mangueirinha-PR |
| River name |
Paraná |
| sub-basin name |
Iguaçu |
| Company name |
Copel Geração S/A. |
| Latitude |
25°47'27"S |
| Longitude |
52°6'50"W |
| Construction Period |
1992 |
| Total installed power(MW) |
1260 |
| Destination of Energy |
SP |
| Historical Maximum discharge(m3/s) |
|
| Mean discharge (m3/s) |
|
| Historical minimum discharge (m3/s) |
|
| Basin area (km2) |
34.10 |
| maximum operational water level (m) |
607.0 |
| extreme maximum water level (m) |
608.0 |
| operational water level (m) |
|
| minimum operational water level (m) |
602.0 |
| Total volume (m3) |
3,000,000,000 |
| Net volume (m3) |
400,000,000 |
| Length (km) |
|
| Surface area at normal condition (km2) |
82 |
| Downstream water level(maximum) (m) |
|
| Downstream water level(normal) (m) |
|
| Downstream water level(minimum) (m) |
|
| Height of the spillway outlet (m) |
|
| Height of the main dam (m) |
145 |
| Length of the main dam(m) |
705 |
| Vaciemiento máximo / Capacidad de descarge del vertedor (m3/s) |
15,800 |
| Tipo |
superfície |
| Número de Compuertas Total |
6 |
| superfície |
|
| Base |
|
| Largo (m) |
|
| Altura (m) |
|
| Cota del tipo de ogiva |
|
| Longitud de la cresta (m) |
104.00 |
| Número de unidades instaladas |
4 |
| Potencial nominal (MW) |
321 |
| Tipo |
Francis |
| Ancho Total (m) |
|
| Largo Total (m) |
|
| Desnível (m) |
|
| Referencia |
|
| Otro información |
|
