Global Lakes & Reservoirs Repository - GLR
| State | Guaíra-SP/ Planura-MG |
|---|---|
| River name | Paraná |
| sub-basin name | Grande |
| Company name | FURNAS |
| Latitude | 20°7'45"S |
| Longitude | 48°34'17"W |
| Construction Period | 1970-1973 |
| Total installed power(MW) | 320 |
| Destination of Energy | SP |
| Historical Maximum discharge(m3/s) | |
| Mean discharge (m3/s) | |
| Historical minimum discharge (m3/s) | |
| Basin area (km2) | |
| maximum operational water level (m) | 467.2 |
| extreme maximum water level (m) | |
| operational water level (m) | 467.2 |
| minimum operational water level (m) | 465.5 |
| Total volume (m3) | 1,525 bilhões |
| Net volume (m3) | 2,335 bilhões |
| Length (km) | |
| Surface area at normal condition (km2) | 143 |
| Downstream water level(maximum) (m) | |
| Downstream water level(normal) (m) | |
| Downstream water level(minimum) (m) | |
| Height of the spillway outlet (m) | |
| Height of the main dam (m) | 40 |
| Length of the main dam(m) | |
| Vaciemiento máximo / Capacidad de descarge del vertedor (m3/s) | 16000 |
| Tipo | segmento |
| Número de Compuertas Total | 9 |
| superfície | |
| Base | |
| Largo (m) | 15 |
| Altura (m) | 15.4 |
| Cota del tipo de ogiva | |
| Longitud de la cresta (m) | |
| Número de unidades instaladas | 4 |
| Potencial nominal (MW) | 80 |
| Tipo | Kaplan |
| Ancho Total (m) | |
| Largo Total (m) | |
| Desnível (m) | |
| Referencia | http://www.mundociencia.com.br/fisica/eletricidade/pcolombia.htm |
| Otro información | T/G supplier: Nohab, ASEA It cost about $63mn (without IDC) and was financially supported by the World Bank. |
